Semi Tubular Rivets

For our complete site on rivets and tools click here!
For rivet nut Tools click here!

Dimension "L" Determined By Application

Jay-Cee Sales and Rivet Inc. offers a large selection of semi tubular and tubular rivets. For more information or to place your order, Call us today!

Semi Tubular Rivet Specifications

DIMENSION "L" DETERMINED BY APPLICATION
Nominal
Shank
Diameter		 Shank Diameter
D		 Head
Style		 Head Diameter
A		 Head Thickness
H		 Hole
Diameter
B		 Hole
Depth
C		 Suggested
Clinch
Allowance		 Hole Dia.
in
Assembly
Min. Max. Basic Tol. Basic Tol. Min. Max
1/16 0.058 0.061 Oval 0.109 ± .005 0.017 ± .002 0.039 0.044 0.046 0.040 0.067
1/16 0.058 0.061 Truss 0.125 ± .005 0.017 ± .002 0.039 0.044 0.046 0.040 0.067
3/32 0.085 0.089 Oval 0.147 ± .005 0.023 ± .003 0.062 0.068 0.064 0.045 0.093
3/32 0.085 0.089 Truss 0.187 + .005 0.023 ± .003 0.062 0.068 0.064 0.045 0.093
3/32 0.095 0.099 Oval 0.156 ± .005 0.023 ± .003 0.070 0.076 0.077 0.050 0.100
3/32 0.095 0.099 Truss 0.187 ± .005 0.029 ± .003 0.070 0.076 0.077 0.050 0.100
1/8 0.118 0.123 Oval 0.218 ± .005 0.034 ± .004 0.084 0.090 0.094 0.075 0.128
1/8 0.118 0.123 Truss 0.281 ± .005 0.034 ± .004 0.084 0.090 0.094 0.075 0.128
9/64 0.141 0.146 Oval 0.234 ± .005 0.040 ± .005 0.100 0.107 0.126 0.092 0.152
9/64 0.141 0.146 Truss 0.312 ± .006 0.040 ± .005 0.100 0.107 0.126 0.092 0.152
5/32 0.151 0.156 Oval 0.312 ±..006 0.046 ±..005 0.110 0.117 0.155 0.096 0.165
5/32 0.151 0.156 Truss 0.328 ± .006 0.046 ± .005 0.110 0.117 0.155 0.096 0.165
3/16 0.182 0.188 Oval 0.312 ±..006 0.060 ±..005 0.134 0.141 0.155 0.120 0.196
3/16 0.182 0.188 Truss 0.375 ±..006 0.060 ±..005 0.134 0.141 0.155 0.120 0.196
1/4 0.244 0.252 Oval 0.437 ± .007 0.068 ± .007 0.176 0.184 0.219 0.157 0.265
1/4 0.244 0.252 Truss 0.500 ± .007 0.078 ± .007 0.176 0.184 0.219 0.157 0.265
5/16 0.302 0.310 Oval 0.500 ± .008 0.093 ± .007 0.211 0.219 0.243 0.188 0.328
5/16 0.302 0.310 Truss 0.562 ± .008 0.093 ± .007 0.211 0.219 0.243 0.188 0.328
3/8 0.370 0.380 Oval 0.500 ± .008 0.125 ± .007 0.276 0.286 0.281 0.219 0.390
3/8 0.370 0.380 Truss 0.750 ± .010 0.156 ± .007 0.276 0.286 0.281 0.219 0.390

Note: Special Sizes or Tolerances Quoted upon request.



Note: Not responsible for errors

in data tables. Please check with

our sales department to confirm specs.
